— PLT-600

PL turnstiles allow free exit out of the site or the building in case of a power failure, a feature mandated by law. If the customer wants the turnstiles remain locked during such an emergency, such functionality can be provided as an option, contingent upon the written request of the client.

DESCRIPTION

PL turnstiles are designed to excel in both internal and external environments. However, for applications in very humid or dusty settings, custom-designed turnstiles with optional features are available if the appropriate specifications are provided at the time of the order. PL turnstiles are ideal for both unidirectional and bidirectional passages which can be free or access- controlled. Even though access in both directions can be controlled by a card-reader, the authorized security personnel of the client can override that setting for card-free access during certain times of the day.

PL turnstiles allow free exit out of the site or the building in case of a power failure, a feature mandated by law. If the customer wants the turnstiles remain locked during such an emergency, such functionality can be provided as an option, contingent upon the written request of the client.

SPECS

  • Operation: Adjustable manual passage to either direction. Optional: Motorized.
  • Chassis: 1.5 mm thick with various color options electrostatic powder coated. Optional AISI 304 quality stainless steel.
  • Moving Gates: 4+4+2 mm laminated glass and desired tint film coating.
    Functions: Height sensor connection (RS 232). Computer control with RS 485. Contact input for 4 reader connections. Automatic evacuation at faulty and forbidden input. Switching information for both directions.
  • Mechanism: 12 bit angular encoder with servo motor control.
  • Emergency Mode: The fire alarm system is switched on automatically when the incoming signal is switched on in both directions.
  • Operating Voltage: 100-230 VAC, 47-60 Hz.
  • Power Consumption: 50W during passages, 25W during stand-by.
  • Operating Temperature: 0º / +55º.
  • Passage Speed: ~5-8 persons/minute.
  • Passage Width: 53 cm.
  • Weight: ~400 kg.
  • Security Level: Very High Security.
  • Areas of Use: Suitable for indoor use.
  • Options: Height Sensor.
